The Properties section contains the general metadata and system-level settings for a Space CE template. These settings apply to all rooms created from the template.
Properties Fields
| Field | Description |
|---|---|
| System Name | The friendly name of the system template, displayed in the Templates list and referenced by rooms. |
| System Repository Name | An auto-populated global identifier used internally by Innomesh. This cannot be changed after creation. |
| System Description | A brief description of the system type and its intended use (e.g., “Meeting Room, Single Display, Zoom Enabled”). |
| Template Version | The configuration version number, formatted as major.minor.revision (e.g., 1.0.0). Increment this when making significant changes to the template. |
| System Type | The room category. Common values include Boardroom, Conference Room, Meeting Room, Teaching Space, Lecture Theatre, and Huddle Space. |
| System Author | Auto-populated with the name of the user who created the template. |
Portability
The Is Portable flag marks rooms created from this template as portable, meaning they are not always expected to be online (e.g., mobile AV carts, temporary installations). When enabled:
- Alerts for devices in portable rooms are diverted to the Suppressed Alerts tab in the Hotlist, preventing noise from expected offline periods.
- The room’s status in Portal will reflect that it is a portable installation.
📝 Note
Changing the portability flag on a template does not retroactively update existing rooms. It applies only to rooms created after the change.
Editing Properties
- Open the Space CE template in Room Manager.
- Click the Properties section in the left-hand navigation.
- Update the desired fields.
- Click Save to apply the changes.
Changes to template properties do not affect rooms that have already been deployed. To update the properties displayed in existing rooms, push the configuration from the template Options menu.
